| 类型 | 毫米的尺寸 | 指定的耦合尺寸 | 指定的故障负载 | ||||
| d | Ø | b | D1 | h | （kn） | ||
| Q-7 | 17 | 22 | 16 | 33.3 | 50 | 16 | 70 |
| QP-7 | 17 | 20 | 16 | 33.3 | 50 | 16 | 70 |
| QP-10 | 17 | 20 | 16 | 33.3 | 50 | 16 | 100 |
| QP-12 | 17 | 24 | 17 | 33.3 | 60 | 16 | 120 |
| QP-12G | 17 | 24 | 17 | 33.3 | 60 | 16 | 120 |
| QP-16 | 21 | 26 | 20 | 41 | 60 | 20 | 160 |
| QP-20 | 25 | 30 | 24 | 49 | 80 | 24 | 200 |
| QP-21d | 21 | 30 | 24 | 41 | 70 | 20 | 210 |
| QP-30 | 25 | 39 | 28 | 49 | 80 | 24 | 300 |
| QP-2120G | 21 | 26 | 20 | 41 | 80 | 20 | 210 |
| QP-3224G | 25 | 33 | 28 | 49 | 80 | 24 | 320 |
| QP-4228G | 29 | 39 | 32 | 57 | 100 | 28 | 420 |
| 类型 | 毫米的尺寸 | 指定的耦合尺寸 | 指定的故障负载 | ||||
| d | Ø | b | D1 | h | （kn） | ||
| Q-7 | 17 | 22 | 16 | 33.3 | 50 | 16 | 70 |
| QP-7 | 17 | 20 | 16 | 33.3 | 50 | 16 | 70 |
| QP-10 | 17 | 20 | 16 | 33.3 | 50 | 16 | 100 |
| QP-12 | 17 | 24 | 17 | 33.3 | 60 | 16 | 120 |
| QP-12G | 17 | 24 | 17 | 33.3 | 60 | 16 | 120 |
| QP-16 | 21 | 26 | 20 | 41 | 60 | 20 | 160 |
| QP-20 | 25 | 30 | 24 | 49 | 80 | 24 | 200 |
| QP-21d | 21 | 30 | 24 | 41 | 70 | 20 | 210 |
| QP-30 | 25 | 39 | 28 | 49 | 80 | 24 | 300 |
| QP-2120G | 21 | 26 | 20 | 41 | 80 | 20 | 210 |
| QP-3224G | 25 | 33 | 28 | 49 | 80 | 24 | 320 |
| QP-4228G | 29 | 39 | 32 | 57 | 100 | 28 | 420 |
